美标UL1569电子线产品特征 1.额定温度：80C 90C105C 2.额定电压：300V 3.执行标准：UL758,UL1581，CSA C22.2 4.导体使用单根或绞合30-2AWG镀锡或裸铜线 5.绝缘采用聚氯乙烯材料 6.通过UL VW-1CSA FT1垂直
立即咨询
| 导体 | 绝缘 | 最大导体电阻 | 耐压强度 | |||
| 规格 AWG | 构造 (No./mm) | 外径 (mm) | 厚度 (mm) | 外径 O.D. (mm) | ||
| 30 | 1/0.254 | 0.25 | 0.40 | 1.05 | 361 | 2,000 |
| 7/0.10 | 0.30 | 0.40 | 1.10 | 381 | ||
| 28 | 1/0.32 | 0.32 | 0.39 | 1.10 | 227 | 2,000 |
| 7/0.127 | 0.38 | 0.41 | 1.20 | 239 | ||
| 7/0.127OS-1 | 0.38 | 0.41 | 1.20 | 239 | ||
| 26 | 1/0.404 | 0.40 | 0.43 | 1.25 | 143 | 2,000 |
| 7/0.16 | 0.48 | 0.41 | 1.30 | 150 | ||
| 7/0.16 OS-1 | 0.48 | 0.41 | 1.30 | 150 | ||
| 24 | 1/0.511 | 0.51 | 0.42 | 1.35 | 89.3 | 2,000 |
| 11/0.16 | 0.61 | 0.40 | 1.40 | 94.2 | ||
| 7/0.200S-1 | 0.60 | 0.41 | 1.40 | 94.2 | ||
| 22 | 1/0.643 | 0.64 | 0.43 | 1.50 | 56.4 | 2,000 |
| 17/0.16 | 0.76 | 0.42 | 1.60 | 59.4 | ||
| 7/0.254 OS-1 | 0.76 | 0.42 | 1.60 | 59.4 | ||
| 20 | 1/0.813 | 0.81 | 0.42 | 1.65 | 35.2 | 2,000 |
| 26/0.16 | 0.94 | 0.43 | 1.80 | 36.7 | ||
| 7/0.32OS-1 | 0.96 | 0.42 | 1.80 | 36.7 | ||
| 18 | 1/1.024 | 1.02 | 0.41 | 1.85 | 22.2 | 2,000 |
| 41/0.16 | 1.18 | 0.46 | 2.10 | 23.2 | ||
| 7/0.4040S-1 | 1.20 | 0.45 | 2.10 | 232 | ||
| 16 | 1/1.29 | 1.29 | 0.46 | 2.20 | 140 | 2,000 |
| 26/0.254 | 1.49 | 0.46 | 2.40 | 14.6 | ||
| 14 | 1/0.160 | 1.60 | 0.45 | 2.50 | 8.78 | 2,000 |
| 41/0.254 | 1.88 | 0.41 | 2.70 | 8.96 | ||
| 12 | 65/0.254 | 2.36 | 0.42 | 3.20 | 5.64 | 2,000 |
| 10 | 105/0.254 | 3.42 | 0.44 | 5.05 | 3.54 | 2,000 |
